3-283-151-11(1)Operating Instructions© 2008 Sony CorporationDVP-NS708HCD/DVDPlayer

10RemoteA TV [/1 (on/standby) button (21)B Z (open/close) button (25)C Number buttons (27)The number 5 button has a tactile dot.*D CLEAR button (30)E

11Guide to the Control Menu Display (Magic Pad)Use the Control Menu to select a function and to view related information. Press DISPLAY repeatedly to

12List of Control Menu itemsz HintThe Control Menu icon indicator lights up in green when you select any item except “OFF” (“PROGRAM,” “SHUFFLE,” “RE

13Guide to the ‘BRAVIA Sync’ DisplayYou can control the player by selecting the SYNC MENU button on the TV’s remote or TV’s option menu.‘BRAVIA Sync’

14HookupsHooking Up the PlayerFollow steps 1 to 6 to hook up and adjust the settings of the player.Notes• Plug cords securely to prevent unwanted nois

15HookupsStep 2: Connecting the Video Cords/HDMI CordsConnect this player to your TV monitor, projector, or audio component such as an AV amplifier (r

16NoteWhen connecting to a progressive TV, it is recommended that you use only pattern C. If you connect to your TV using both C and D, a special cont

17Hookups• When you connect the player to your TV via the SCART jacks, the TV’s input source is set to the player automatically when you start playbac

18Step 3: Connecting the Audio CordsSelect one of the following patterns A or B according to the input jack on your TV monitor, projector, or audio co

19HookupsA Audio L/R input jacksThis connection will use your TV’s or audio component’s two speakers for sound.B Digital audio input jackIf your audio

2WARNINGTo reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.To avoid electrical shock, do not open the cabi

20Step 4: Connecting the Mains LeadPlug the player and TV mains lead (power cord) into a mains.Step 5: Preparing the RemoteYou can control the player

21HookupsControlling Your TV with the Supplied RemoteYou can control the sound level, input source, and power switch of your Sony TV with the supplied

22Step 6: Quick SetupFollow the steps below to make the minimum number of basic adjustments for using the player.To skip an adjustment, press >. To

23Hookups8 Press ENTER.The Setup Display for selecting the type of video signal output from the LINE (RGB)-TV jack appears.9 Press X/x to select the t

24PlaybackPlaying Discs Depending on the DVD or VIDEO CD, some operations may be different or restricted.Refer to the operating instructions s

25PlaybackNotes on playing DTS sound tracks on a DVD VIDEO• DTS audio signals are output only through the DIGITAL OUT (COAXIAL)/HDMI OUT jack.• When y

26Locking the disc tray (Child Lock)You can lock the disc tray to prevent children from opening it.When the player is in standby mode, press O RETURN,

27PlaybackThe options for “ORIGINAL/PLAY LIST” appear.3 Press X/x to select a setting.• PLAY LIST: plays the titles created from “ORIGINAL” for editin

28If an MP3 audio track has an ID3 tag, the player will display the album name/track title from the ID3 tag information.ID3 tag information for MP3 au

29PlaybackWhen playing a VIDEO CD (without PBC functions) or CDz Hints• When playing VIDEO CDs without PBC functions, the track number, and the index

3Notes About the Discs• To keep the disc clean, handle the disc by its edge. Do not touch the surface. Dust, fingerprints, or scratches on the disc ma

303 Press X/x to select “SET t,” then press ENTER.4 Press c.The cursor moves to the title or track row “T” (in this case, “01”).5 Select the title, ch

31Playback3 Follow step 5 for new programming. To cancel a programme, select “--” under “T,” then press ENTER.To cancel all of the titles, chapters, o

32◆ When playing in DVD-VR mode• DISC: repeats all the titles of the selected type.• TITLE: repeats the current title on a disc.• CHAPTER: repeats the

33PlaybackAdjusting the Playback Picture (CUSTOM PICTURE MODE) You can adjust the video signal of the DVD, VIDEO CD, DATA CD/DATA DVD in JPEG for

344 Repeat step 2 and 3 to adjust “BRIGHTNESS,” “COLOR,” and “HUE.”To turn off the displayPress O RETURN or DISPLAY.Notes• This function does not work

35PlaybackAdjusting the Delay Between the Picture and Sound (AV SYNC) When the sound does not match the pictures on the screen, you can adjust th

36Locking Discs (CUSTOM PARENTAL CONTROL, PARENTAL CONTROL)You can set two kinds of playback restrictions for a disc.• Custom Parental ControlYou can

37Playback2 Enter your 4-digit password using the number buttons, then press ENTER.The player is ready for playback.z HintIf you forget your password,

38Notes• When you play discs which do not have the Parental Control function, playback cannot be limited on this player.• Depending on the disc, you m

39Searching for a SceneSearching for a SceneSearching for a Particular Point on a Disc (Scan, Slow-motion Play, Freeze Frame)You can quickly locate a

4Table of ContentsWARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2Notes About the Dis

40Playing one frame at a time (Freeze Frame) When the player is in the pause mode, press (step) to go to the next frame. Press (step) to go to t

41Searching for a Scene◆ When playing a VIDEO CD or Super VCD without PBC Playback TRACK INDEX◆ When playing a VIDEO CD or Super VCD with PBC Playback

42Searching by Scene (PICTURE NAVIGATION) You can divide the screen into 9 subscreens and find the desired scene quickly.1 Press PICTURE NAVI during

43Sound AdjustmentsSound AdjustmentsChanging the Sound When playing a DVD VIDEO or DATA CD (DivX video files)/DATA DVD (DivX video files) record

44Notes• While playing a Super VCD on which the audio track 2 is not recorded, no sound will come out when you select “2:STEREO,” “2:1/L,” or “2:2/R.”

45Sound AdjustmentsTV Virtual Surround Settings (TVS) When you connect a stereo TV or 2 front speakers, TVS (TV Virtual Surround) lets you enjoy surro

46Enjoying MP3 Audio and JPEG ImagesAbout MP3 Audio Tracks and JPEG Image FilesMP3 is audio compression technology that satisfies the ISO/IEC MPEG reg

47Enjoying MP3 Audio and JPEG ImagesWhen you insert a DATA CD/DATA DVD and press H, the numbered tracks (or files) are played sequentially, from 1 thr

48To select JPEG image files, see “Selecting a JPEG image file” (page 48).To stop playbackPress x.To go to the next or previous pagePress c or C.To tu

49Enjoying MP3 Audio and JPEG Images◆When pressed once (x2)The image enlarges twice the original size.◆When pressed twice (x4)The image enlarges four

5Enjoying DivX® Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53About DivX Video Files . . . . . . . . . . . . . . . . . . .

50Viewing a slide show with sound (MODE (MP3, JPEG))You can enjoy a slide show with sound.1 Press DISPLAY during stop mode.The Control Menu appears.2

51Enjoying MP3 Audio and JPEG ImagesOn “PhotoTV HD”“PhotoTV HD” allows for highly-detailed pictures, and photo-like expression of subtle textures and

52Selecting the slides’ appearance (EFFECT)You can select the way the slides are displayed during a slide show.1 Press DISPLAY twice while viewing a J

53Enjoying DivX® VideosEnjoying DivX® VideosAbout DivX Video FilesDivX® is a video file compression technology, developed by DivX, Inc. This product i

54Playing DivX Video Files You can play DivX video files on DATA CDs and DATA DVDs.z HintYou can view the disc information while playing a DivX vide

55Settings and AdjustmentsSettings and AdjustmentsUsing the Setup DisplayBy using the Setup Display, you can make various adjustments to items such as

566 Press X/x to select a setting, then press ENTER.The setting is selected and setup is complete.Example: “4:3 PAN SCAN”To enter the Quick Setup mode

57Settings and AdjustmentsSettings for the Display (SCREEN SETUP)Choose settings according to the TV to be connected.Select “SCREEN SETUP” in the Setu

58◆ LINESelects video signals output from the LINE (RGB)-TV jack on the rear panel of the player.Notes• If your TV does not accept S video or the RGB

59Settings and AdjustmentsCustom Settings (CUSTOM SETUP)Use this to set up playback related and other settings.Select “CUSTOM SETUP” in the Setup Disp

6This Player Can Play the Following Discs“DVD+RW,” “DVD-RW,” “DVD+R,” “DVD+R DL,” “DVD-R,” “DVD VIDEO,” and “CD” logos are trademarks.Note about CDs/D

60Settings for the Sound (AUDIO SETUP)“AUDIO SETUP” allows you to set the sound according to the playback and connection conditions.Select “AUDIO SETU

61Settings and Adjustments◆ DOLBY DIGITAL (DVDs only)Selects the type of Dolby Digital signal.NoteIf the HDMI OUT jack is connected to equipment not c

62HDMI Settings (HDMI SETUP)“HDMI SETUP” allows you to adjust items related to the HDMI connection.Select “HDMI SETUP” in the Setup Display. To use th

63Settings and Adjustments• When you set to “PhotoTV HD,” the player changes video signal output from “HDMI RESOLUTION” to “1920×1080i,” “TV TYPE” to

64Additional InformationTroubleshootingIf you experience any of the following difficulties while using the player, use this troubleshooting guide to h

65Additional Information, The player is in pause mode or in Slow-motion Play mode., The player is in fast forward or fast reverse mode., If the audio

66The player’s internal background sound and JPEG image files start playing simultaneously., “MODE (MP3, JPEG)” is set to “AUTO (BGM)” (page 50).The D

67Additional InformationThe disc tray does not open and “LOCKED” appears on the front panel display., Child Lock is set (page 26).The disc tray does n

68Self-diagnosis Function (When letters/numbers appear in the display)When the self-diagnosis function is activated to prevent the player from malfunc

69Additional InformationSpecificationsSystemLaser: Semiconductor laserOutputs(Jack name: Jack type/Output level/Load impedance)LINE OUT (AUDIO): Phono

7Notes• Notes about DVD+RWs/DVD+Rs/DVD+Rs DL, DVD-RWs/DVD-Rs/DVD-Rs DL, or CD-Rs/CD-RWsSome DVD+RWs/DVD+Rs/DVD+Rs DL, DVD-RWs/DVD-Rs/DVD-Rs DL, or CD-

70Language Code ListFor details, see pages 43, 56.The language spellings conform to the ISO 639: 1988 (E/F) standard.Parental Control Area Code ListFo

71Additional InformationIndexNumerics16:9 574:3 LETTER BOX 574:3 OUTPUT 584:3 PAN SCAN 5748kHz/96kHz PCM 615.1 Channel Surround 19AA-B REPEAT 32ADVANC

Sony Corporation Printed in MalaysiaPrinted on 70% or more recycled paper using VOC (Volatile Organic Compound)-free vegetable oil based ink.z To fi

8Guide to Parts and ControlsFor more information, see the pages indicated in parentheses.Front panelA [/1 (on/standby) button (24)B Disc tray (24)C Fr

9Front panel displayWhen playing back a DVDWhen playing back a VIDEO CD with Playback Control (PBC) (27)When playing back a CD, DATA CD (MP3 audio/Div
